Body Shells |
 |
| KA1MGM |
Body shell assembly Sprite/Midget G-AN4,H-AN9
required quantities: 1
|
| KA1aMGM |
Body shell assembly Sprite/Midget G-AN5 to 105500,H-AN10, A-AN10
required quantities: 1
|
| KA1bMGM |
Body shell assembly Sprite/Midget G-AN5 from 105501
required quantities: 1
|
| KA1MGM/1500 |
Body shell assembly Midget 1500 G-AN6
required quantities: 1
|
| |
Front Wings Shells |
|
| KA7MGM/L |
Rear, 1/4 repair, LH front wing Sprite MK2-4 / Midget MK1-3
required quantities: 1
|
| KA7MGM/R |
Rear, 1/4 repair, RH front wing Sprite MK2-4 / Midget MK1-3
required quantities: 1
|
| KA7MGM/1500-L |
Rear, 1/4 repair, LH front wing Midget 1500
required quantities: 1
|
| KA7MGM/1500-R |
Rear, 1/4 repair, RH front wing Midget 1500
required quantities: 1
|
| KA10MGM/1275L |
Front wing, LH Sprite from H-AN9-77591,H-AN10,A-AN10 / Midget from G-AN4-66226,G-AN5
required quantities: 1
|
| KA10MGM/1275R |
Front wing, RH Sprite from H-AN9-77591,H-AN10,A-AN10 / Midget from G-AN4-66226,G-AN5
required quantities: 1
|
| KA10MGM/1500L |
Front wing, LH Midget 1500
required quantities: 1
|
| KA10MGM/1500R |
Front wing, RH Midget 1500
required quantities: 1
|
| KA10MGM/L |
Front wing, LH Sprite MK2-3 to H-AN9-77590 / Midget MK1-2 to GAN4-66225
required quantities: 1
|
| KA10MGM/R |
Front wing, RH Sprite MK2-3 to H-AN9-77590 / Midget MK1-2 to GAN4-66225
required quantities: 1
|
| KA15MGM |
Headlamp mounting repair all Sprite/Midget models
required quantities: 1
|
| |
Front End Assembly |
|
| KA23MGM |
Stiffener, front valance Sprite MK2-4 / Midget MK1-3
required quantities: 1
|
| KA24MGM |
Mounting tray, with sides Sprite MK2-4 / Midget MK1-3
required quantities: 1
|
| KA25MGM |
Mounting tray Sprite MK2-4 / Midget MK1-3
required quantities: 1
|
| KA26MGM |
Front end Sprite MK2-4 / Midget MK1-3
required quantities: 1
|
| KA26MGM/1500 |
Front end Midget 1500
required quantities: 1
|
| KA26aMGM |
Front end assembly Sprite MK2-3 / Midget MK1-2
required quantities: 1
|
| KA27aMGM |
Front valance (skin & stiffener) Sprite MK2-4 / Midget MK1-3
required quantities: 1
|
| KA27aMGM/1500 |
Front valance (skin & stiffener) Midget 1500
required quantities: 1
|
| KA27MGM |
Outer skin, front valance Sprite MK2-4 / Midget MK1-3
required quantities: 1
|
| KA27MGM/1500 |
Outer skin, front valance Midget 1500
required quantities: 1
|
| |
Outer Sills |
|
| KA16AH/SP-L |
Outer sill, LH Sprite MK2-4 / Midget MK1-3,1500 up to GAN6-157671
required quantities: 1
|
| KA16AH/SP-R |
Outer sill, RH Sprite MK2-4 / Midget MK1-3, 1500 up to GAN6-15671
required quantities: 1
|
| KA16MGM/1500L |
Outer sill, LH Midget 1500 from GAN6-157672
required quantities: 1
|
| KA16MGM/1500R |
Outer sill, RH Midget 1500 from GAN6-157672
required quantities: 1
|
| KA508MGM/L |
Filler, outer sill, front, LH all Sprite/Midget
required quantities: 1
|
| KA508MGM/R |
Filler, outer sill, front, RH all Sprite/Midget
required quantities: 1
|
| KA509MGM/L |
Filler, outer sill, rear, LH all Sprite/Midget
required quantities: 1
|
| KA509MGM/R |
Filler, outer sill, rear, RH all Sprite/Midget
required quantities: 1
|
| |
Rear Wings |
|
| KA18AH/SP/L |
B Post LH Sprite MK2 / Midget MK1
required quantities: 1
|
| KA18AH/SP/R |
B Post RH Sprite MK2 / Midget MK1
required quantities: 1
|
| KA18MGM/L |
B Post LH Sprite MK3-4 / Midget MK2-3,1500
required quantities: 1
|
| KA18MGM/R |
B Post RH Sprite MK3-4 / Midget MK2-3,1500
required quantities: 1
|
| KA20MGM/MK1-L |
Rear wing, LH Sprite MK2/ Midget MK1
required quantities: 1
|
| KA20MGM/MK1-R |
Rear wing, RH Sprite MK2/ Midget MK1
required quantities: 1
|
| KA20MGM/MK2-L |
Rear wing, LH Sprite MK3/ Midget MK2
required quantities: 1
|
| KA20MGM/MK2-R |
Rear wing, RH Sprite MK3/ Midget MK2
required quantities: 1
|
| KA20MGM/MK3LF |
Rear wing, (less B-Post) LH Sprite/Midget G-AN4, GAN5 bis 105500, H-AN9,H-AN10,A-AN10
required quantities: 1
|
| KA20MGM/MK3RF |
Rear wing, (less B-Post) RH Sprite/Midget G-AN4, GAN5 bis 105500, H-AN9,H-AN10,A-AN10
required quantities: 1
|
| KA20MGM/MK3LS |
Rear wing, LH Sprite/Midget GAN5 ab 105501
required quantities: 1
|
| KA20MGM/MK3RS |
Rear wing, RH Sprite/Midget GAN5 ab 105501
required quantities: 1
|
| KA20MGM/1500L |
Rear wing, LH Midget GAN6
required quantities: 1
|
| KA20MGM/1500R |
Rear wing, RH Midget GAN6
required quantities: 1
|
| KA21MGM/L |
Front, 1/4 repair, LH, rear wing Sprite MK2,MK3,MK4 / Midget MK1,MK2,MK3,1500
required quantities: 1
|
| KA21MGM/R |
Front, 1/4 repair, RH, rear wing Sprite MK2,MK3,MK4 / Midget MK1,MK2,MK3,1500
required quantities: 1
|
| KA22MGM/L |
Rear, 1/4 repair, LH, rear wing Sprite MK2,MK3,MK4/ Midget MK1,MK2,MK3,1500
required quantities: 1
|
| KA22MGM/R |
Rear, 1/4 repair, RH, rear wing Sprite MK2,MK3,MK4/ Midget MK1,MK2,MK3,1500
required quantities: 1
|
| KA28MGM/L |
Lower, 1/2 repair, LH, rear wing Sprite MK2,MK3,MK4 / Midget MK1,MK2,MK3,1500
required quantities: 1
|
| KA28MGM/R |
Lower, 1/2 repair, RH, rear wing Sprite MK2,MK3,MK4 / Midget MK1,MK2,MK3,1500
required quantities: 1
|
| KA30MGM |
Beading Sprite MK4 / Midget MK3,1500
required quantities: 1
|
| KA31MGM |
Plate, tapped, upper Sprite MK4/ Midget MK3,1500
required quantities: 2
|
| KA32MGM |
Plate, tapped, lower Sprite MK4/ Midget MK3,1500
required quantities: 2
|
| KA50MGM/L |
Rear wing, LH Sprite/Midget G-AN4, GAN5 bis 105500, H-AN9,H-AN10,A-AN10
required quantities: 1
|
| KA50MGM/R |
Rear wing, RH Sprite/Midget G-AN4, GAN5 bis 105500, H-AN9,H-AN10,A-AN10
required quantities: 1
|
| |
Rear shroud |
|
| KA19MGM/L |
Shroud side repair panel, LH Sprite MK2,3 Midget MK1,2
required quantities: 1
|
| KA19MGM/R |
Shroud side repair panel, RH Sprite MK2,3 Midget MK1,2
required quantities: 1
|
| KA29MGM |
Rear panel, no holes Sprite MK2,MK3,MK4 / Midget MK1,MK2,MK3,1500
required quantities: 1
|
| KA33AMGM |
Stiffener, rear deck Sprite MK4 / Midget MK3,1500
required quantities: 1
|
| KA33MGM |
Rear deck Sprite MK4 / Midget MK3,1500
required quantities: 1
|
| KA34MGM/L |
Rear shroud side, LH Sprite MK4 / Midget MK3,1500
required quantities: 1
|
| KA34MGM/R |
Rear shroud side, RH Sprite MK4 / Midget MK3,1500
required quantities: 1
|
| KA35MGM |
Rear panel, (chrom quarter bumpers) Midget/Sprite 1275
required quantities: 1
|
| KA36MGM |
Rear panel ( rubber bumpers) Midget 1500
required quantities: 1
|
| KA38MGM |
Boot lid Sprite MK2,MK3/Midget MK1,MK2
required quantities: 1
|
| KA39MGM |
Outer skin, boot lid Sprite MK2,MK3/Midget MK1,MK2
required quantities: 1
|
| |
Bonnet |
|
| KA37MGM |
Bonnet Sprite MK2-3 / Midget MK1-3, 1500 to GAN6-183739
required quantities: 1
|
| KA37MGM/1500 |
Bonnet Midget 1500 from GAN6-183740
required quantities: 1
|
